150bar 10Nm3/h Propeller Oil Free Oil Free Oxygen Gas Compressor

1.0 Sets
MOQ
150bar 10Nm3/h Propeller Oil Free Oil Free Oxygen Gas Compressor
Features Gallery Product Description Request A Quote
Features
Specifications
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Bevera
Showroom Location: None
Condition: New
Type: Screw
Configuration: Stationary
Power Source: Diesel
Lubrication Style: Oil-free
Mute: Yes
Voltage: Customer's Requirement
Warranty: 1 Year
Working Pressure: 14 Bar, 7 Bar, 8 Bar, 0.8 Bar, 2 Bar, 20 Bar, 13 Bar, 6 Bar, 12 Bar, 1 Bar, 10 Bar, 35 Bar, 5 Bar, 0.4 Bar, 0.6 Bar
Machinery Test Report: Provided
Video Outgoing-inspection: Provided
Marketing Type: New Product 2019
Warranty Of Core Components: 1.5 Years
Core Components: PLC, Pressure Vessel, Engine, Motor, Pump, Bearing
Gas Type: Oxygen
After Warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location: None
After-sales Service Provided: Online Support
Basic Infomation
Payment & Shipping Terms
Packaging Details: Wooden box
Supply Ability: 1000 Set/Sets per Month
Product Description
Product Description Whatsapp:008618936889762
Our company produced many kinds of oil free compressor, inlcuding oil free air compressor, oil free gas compressor, including oxygen gas, nitrogen gas, hydrogen gas, natural gas, Argon gas, helium gas, Sf6 gas ects more than thirty kinds of gas medium,max pressure up to 40Mpa.
Our oxygen compressor is total oil free, do not use any lubricate oil, and for the cylinder use stainless steel material, piston
ring is self-lubricated material, all this guarantee oxygen is clean and no-pollution. Compressor working speed is slow, normally 200-400 rpm, to keep working do 24 hours heavy duty loading, this Oxygen compressor main use for hospital oxygen supplier center, to increase oxygen supply line pressure to the room, also can boost oxygen, and filling to the cylinder, such as 15Mpa, 20Mpa, also our oxygen booster, can use in Industrial acetylene cutting, cutting steel scrap in steel factory, support Boiler oxygen combustion recycle the cryogenic liquid oxygen tank vapor oxygen to the tank.
Normally, according to customer oxygen application condition, our oxygen compressor has one pressure stage, two pressure stage, three pressure stage, and four pressure stage, and five pressure stage, by the cylinder, has single, double, three, and four cylinder.
Oilless High Pressure O2 Compressor Specification
NO.
Volume
Inlet pressure
Outlet pressure
Type
Cooling type
1
1-3m³
0.3-0.4MPa
15MPa
2 lines 4 stages vertical type
Wind
2
4-12m³
0.3-0.4MPa
15MPa
2 lines 4 stages vertical type
Wind
3
13-40m³
0.3-0.4MPa
15MPa
3 lines 3 stages W type
Water
4
13-60m³
0.2-0.4MPa
15MPa
2 lines 4 stages vertical type
Water
5
40-80m³
0.2-0.4MPa
15MPa
4 lines 4 stages S type
Water
6
80-120m³
0.2-0.4MPa
15MPa
4 lines 4 stages S type
Water

Low Pressure O2 Booster Compressor Performance Characteristics

1.Air cooled or water-cooled type 2.Power range: ≤55KW
3.Speed range: 300-600r/min
4.Flow range: 1000Nm³/h
5.Inlet pressure:0-0.6MPa
6.Outlet pressure: ≤10MPa
7.Compression stage: 1-4 stages
CONTACT US
Whatsapp/Mob: +86 18936889762; Email: gaoyuu@njbangwin.com
Application Show Whatsapp:0086 18936889762
Our Factory

The production base covers an area of about 50 acres and has a modern standard factory building with a construction area of nearly 14,000 meters. More than 120 employees, more than 40 college graduates, 18 professional R & D personnel, first-line operators are technical experts with special operational skills.
FAQ
If you have compressor inquiry please tell us follows information when you send inquiry:
*Compressor working medium: If single gas ,how many purity ? if mixed gas , what’s gas content lit ?
*Suction pressure(gauge pressure):_____bar
*Exhaust pressure(gauge pressure):_____bar
*Flow rate per hour for compressor: _____Nm³/h
Compressor gas suction temperature:_____℃
Compressor working hours per day :_____hours
Compressor working site altitude :_____m
Environment temperature : _____℃
Has cooling water in the site or not ?______
Voltage and frequency for three phase :____________
Do not has water vapor or H2S in the gas ?______
Application for compressor?__________
